Home > 3G/3.5G USB Adapter or Modem Connector Type


3G/3.5G USB adapter & Modem attachment data sheet This list is for your reference only.
We strongly recommend that you consult with your hardware manufactory to make sure what the correct connector type you need.

Select Connector
Wireless Product USB Connector
Click photo for large view
Ericsson TOP
W25

SMA Male

W30, W35

MCX-Plug (Male)

Huawei TOP
B970

SMA Male

E122, E156, E156G, E160, E160E, E160G, E1612, E161, E169, E176, E176, E1762, E196G, E1820, EC321, EC881E, E600, E612, E618, E620, E621, E630, E660A, E660, K3520, UMG 181, UMG 1691, UMG1691, UMG181

CRC9

E800, E870, E880

SSMB

Maxon TOP
Turbo II, Turbo III

SMA Male

Netcomm TOP
3G10WV, 3G9W, 3G9WB, 3G9WT

SMA Male

Novatel Wireless TOP
MC727, M760, U727, U760, USB727, USB760

TS-9

Option Wireless TOP
3G QUAD, 7.2 HSDPA, EDGE, Express, Express HSUPA, Fusion, GlobesurferII, GlobesurferIII, GT Max, HSDPA, Max HSDPA

MC Card

Sierra Wireless TOP
Air Card 555D, Air Card 580, Air Card 597E, Air Card 775, Air Card 850, Air Card 860, Air Card 875, Air Card 880, Air Card 880E, Air Card 880U, Air Card 881, Air Card 881E, Air Card 881U, APEX 880

SSMB

Air Card 305, Air Card 402, Air Card 501, Air Card 502, Air Card 503, Compass 597, Compass 885, Compass 888,Compass 889, USB305, USB306, USB307, USB308, USB309, USB598

TS-9

Sony Ericsson TOP
EC400, EC400G, PC300

SSMB

ZTE TOP
MF633+, MF633BP+, MF645, MF668, MF668+

TS-9
